Front Axle Brake Disc
BLUE PRINT ADK84342
Front Axle
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
Related Parts / Accessories:
- 1 x ADBP550010 High Temperature Lubricant
- 1 x ADG05534 High Temperature Lubricant
Specifications
Brake Disc Thickness [mm]
17mm
Rim Hole Number
5-Hole
Number of mounting bores
2
Thickness [mm]
46mm
Outer Diameter [mm]
287mm
Bolt Hole Circle Ø [mm]
140mm
Surface
Coated
Brake Disc Type
internally vented
Fitting Position
Front Axle
Minimum thickness [mm]
15mm
Centering Diameter [mm]
108mm
Weight [kg]
4.58kg
Observe service information
EAN / Barcode
5050063120721
OEM Part Numbers
- SUZUKI 55211-76J10
- SUZUKI 55211-76J11
