Front Axle Brake Disc
BLUE PRINT ADG043175
Front Axle
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
Specifications
Brake Disc Thickness [mm]
23mm
Rim Hole Number
5-Hole
Number of mounting bores
2
Thickness [mm]
45mm
Outer Diameter [mm]
280mm
Bolt Hole Circle Ø [mm]
114mm
Surface
Coated
Brake Disc Type
internally vented
Fitting Position
Front Axle
Minimum thickness [mm]
21.4mm
Centering Diameter [mm]
69mm
Weight [kg]
6.62kg
Observe service information
EAN / Barcode
5050063103625
OEM Part Numbers
- HYUNDAI 51712-2V000
- HYUNDAI 51712-3X000
- KIA 51712-2V000
